Specifications
| Sensor type | Uncooled Detector |
| Response band | 7.5 ~ 14µm |
| NETD (Noise Equivalent Temperature Difference) | ＜50mk（@25℃，F#=1.0） |
| Maximum image size | 192×144 |
| Thermal imagery lens focal length | 3.5mm |
| Minimum imagery distance | 0.3m |
| Field of view | 37.5°x28° |
| Number zoom | 1X~ 4X, minimum change 0.1X |
| frame rate | 25Hz |
| Pixel size | 12µm |
| F value | F1.1 |
| temperature Measurement Range | -20°C~400°C |
| Accuracy | +/- 2 ° or +/- 2%, MAX Maximum |
| Spatial resolution (IFOV) | 3.43mrad |
| Visible light maximum image size | 3264×2448 |
| Visible image resolution | 1600x1200 |
| Visible video resolution | 1600x1200 |
| display | 3.5 "LCD capacitive touch screen 640 × 480 |
| Image mode | Support 7 pseudo-color modes such as rainbow and iron red |
| Screen display mode | Visible light, thermal imagery, dual light fusion, PIP |
| Temperature measurement rules | Support hot, cold, and center points |
| UVC screen projection | support |
| Battery Capacity | 2100mAh |
| Charging time | 1.5 hours fast charge to 94% battery, 2.5 hours full charge |
| Bluetooth | support |
| take a picture | Thermal imagery, visible light, dual light fusion, PIP |
| video recording | Thermal imagery, visible light, dual light fusion, PIP |
| lighting | support |
| Text annotation | support |
| interface language | Chinese |
| WIFI | support |
| storage | 16GB |
| Hardware interface | TYPE-C |
| Battery type | Li-ion battery |
| Battery Working time | 4h |
| Tripod mount | Support, standard UNC ¾ "-20 hole position |
| Operating temperature and Humidity | -10°C~50°C，≤95% |
| Protection class | IP54 |
| anti-drop grade | 2m |
| Weight | 218g |
| size | 138.5mm×85.2mm×23.6mm |
| PC software | Support for HikmicroAnalyzer client side |
| App | Support Lighting Heat Vision APP |
| screen projection | Support UVC screen projection |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
