Specifications
| Wavelength range | 380~780nm |
| Wavelength resolution | 0.6nm/pixel |
| Wavelength Precision | 0.3nm |
| observation field of view | 8° |
| Measurement of field of view | 1° |
| Minimum measurement distance | 300Mm (focal length: 85mm, standard lens) |
| Minimum measurement area | Measurement area 400mm, approx. |
| Measurement luminance range (Standard A Light source) | 0.1~ 600000/60000000cd/m2 (with attenuator) |
| Measurement Accuracy of luminance | 2% reading + 1 word (according to the national Measurement verification regulations JJG211-2005 method inspection) |
| Luminance Repeatability | 0.3% (1cd/m2 or more) |
| Chroma Precision (Standard A Light source) | x,y:0.0015 (4cd/m 2 ル) |
| Chroma Repeatability (Standard A Light source) | x,y: 0.0006 (4cd/m 2 ル) |
| interface | USB、WIFI |
| size | 160mm×150mm×350mm |
| Weight | 3.0kg |
Packing list
