Specifications
| Temperature range | RT+~400℃ |
| Measuring method | Automatic/visual (high definition camera, video capture, playback monitoring) |
| processing power | 2 channel |
| Measuring method | 200 kinds |
| user management | 200 (Level 4 permissions) |
| Audit Trail | Optional (FDA software) |
| Electronic signature | Yes. |
| Temperature Resolution | 0.1℃ |
| Heating rate | 0.1 ℃/min- 20 ℃/min optional continuously |
| Operating system | Android Operating system (can be connected to LIMS system) |
| data storage space | 128G |
| printer | Optional: micro printer (needle type, thermal); WIFI printer |
| Display mode | 10.1 inch IPS capacitive touch screen 720P high definition camera |
| communication interface | 1 x RS232、3 x USB、1 x RJ-45 |
| Power supply Voltage | 100~240V，50/60Hz，150w |
| instrument size | 320mm x 295mm x 190mm |
| Net Weight of instrument | 3.7 kg |
| material | plastic |
| principle | The state of matter changes with temperature, and the deformation image is automatically interpreted. |
| function | Automatic measurement of material temperature deformation characteristics. |
| Export preferences | Uncertain |
| detection object | Resin |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/42608/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
