Specifications
| Dynamic mode | compressed air |
| Power Supply | AC 220V 50Hz |
| Pressure range | 0~-90kPa |
| Pressure Accuracy | ± 0.1kPa |
| Pressure acquisition speed | 3ms |
| Supplementary pressure reaction speed | 5ms |
| control mode | Microcomputer control, fully automated testing |
| display mode | 5-Inch LCD screen display |
| time frame | 0~6000S (can be increased) |
| Air source pressure | 0.7Mpa (air source user-provided, optional) |
| Air source interface | φ 6 polyurethane tube |
| Effective size of vacuum chamber | Φ270*210mm |
| Host Dimensions | 420(L)×320(B)×120(H)mm |
| Sealing barrel Dimensions | Φ300×350mm (H) |
| net Weight | About 16KG |
| Standard configuration | Host, sealing barrel, trachea, power cord, manual |
| reference standard | GB/T 15171、ASTM D3078 |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/42660/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
