Specifications
| Measurement range | 250~6000KPa (Cardboard), 70~1600KPa (paper) |
| Chuck Clamping Force | ≥ 690kPa (Cardboard), ≥ 430kPa (paper) |
| Pressurized oil feeding speed | 170 +/- 15ml/min (Cardboard), 95 +/- 5ml/min (paper) |
| Wax resistance | 170-220kpa when the raised height is 10 mm; 250-350kpa when the raised height is 18mm |
| Complete-built unit Accuracy | Level 1 (resolution: 1kPa) |
| Indication Precision | ±0.5%F.S |
| Hydraulic system sealing | At the upper limit of measurement, 1 minute pressure drop < 10% Pmax |
| Sample clamp ring size | Upper and lower clamp ring aperture φ31.5 +/- 0.05mm (Cardboard), Upper/Lower aperture φ30.5 +/- 0.1mm, φ33.1 +/- 0.1mm (paper) |
| Motor Power | 90W |
| Dimensions | 500×250×250mm |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/42681/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
