Specifications
| test force | 500, 1000, 2000, 3000N optional |
| Operation mode | Five-inch color LCD touch screen, |
| Measurement range | 2%~ 100% of the maximum test force |
| Accuracy level | ±1% |
| Test Force Precision | +/- 1% better than indication |
| Deformation display error | ≤±(50+0.15L) |
| test force | Minimum resolution 0.01N |
| Displacement measurement | Resolution is 0.01mm |
| Deformation Precision | Better than +/- 1% |
| LCD content | Test force, displacement, peak value, running state, running speed, etc |
| stepless speed regulation | Stepper Motor and Control system |
| Drive mode | Stepper motor, synchronous belt drive |
| Motor Power | 150W |
| Speed regulation range | 1mm/min~500mm/min |
| test stroke | 800mm (can be customized) |
| stretch space | 800mm (can be customized) |
| Host size | 500*420*1550mm |
| Test protection function | Overload protection, leakage protection, limit protection |
| Power supply | 220V 50Hz |
| Weight | About 80Kg |
| Standard configuration | Main unit, standard fixture, auxiliary device, power cord, technical document |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/42685/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
