Specifications
| Specimen size | 38 * 70mm (standard size) |
| Actual measurement size | 38 * 50mm (standard) |
| span range | Span length 1~ 60mm, 5mm, 10mm, 15mm, 20mm, 25mm, 30mm, 40mm, 50mm, 8-speed arm adjustable. |
| Span Accuracy | ±0.1mm |
| Sensors | Sensing Accuracy +/- 0.1% |
| Resolution | 0.01mN |
| Bending angle | 0~90 ° stepless adjustable |
| Angle measurement | Single angle per measurement, stepless selection in the range of 0~90 ° |
| Angular velocity control | Adjustable 0.5 - 50 °/sec, independently adjustable for three test angles and durations |
| Angle Accuracy | ±0.1 |
| Film thickness measurement | Film thickness in (0.01~ 5.0) mm paper and other composite |
| Bending time | Choose different bending times based on material resilience |
| Specimen holder | Manual fixture operation, automatic reset after test completion |
| Operating interface | 7Inch touch screen Operating interface, visual menu operation. |
| Clamping method | Unlimited blessing, nondestructive continuous clamping |
| Signal output | Standard computer signal output, link computer, computer operating platform, can realize document editing (optional) |
| Self-calibrating | Equipment can be self-calibrated, standard calibrating tools |
| printout | Modular integrated thermal printer |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/42689/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
