Specifications
| Measurement range | 1~ 99999 times |
| folding angle | 135°±2° |
| folding speed | 175±10cpm |
| Tension range | 4.9N, 9.81N, 14.7N adjustable |
| Clip width | 15 ± 0.1mm |
| Fold mouth fillet radius | R0.38mm ± 0.02mm |
| Folding mouth gap distance | 0.25mm 0.50mm; 0.75mm; 1.00mm |
| Sample size | 15Mm wide, longer than 140mm |
| test group | 1 group |
| interface | 5-Inch color touchscreen |
| output | Thermal printer |
| Power supply Voltage | 220 VAC, 50 Hz |
| Dimension | 330*290*510mm |
| Weight | 25 kg |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/42695/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
