Specifications
| Power | AC220V±10% 2A 50Hz |
| Error of indication | ±0.5% |
| Indication of variability | ≤0.5% |
| Resolution | 0.1 kPa |
| Measurement range | 250 ~ 5600kPa |
| Clamping Force | ≤ 1200kPa (adjustable) |
| Air compressor | Pressure (0.6~ 0.7) MPa; Displacement (0.02~ 0.3) m3/min (non-standard); |
| System sealing | 1Min pressure drop < 10% FS |
| Human Machine Interface | 7-Inch LCD or color touch screen, Chinese and English menus |
| printout | Modular integrated thermal printer |
| Operating Environment | Indoor temperature (20 +/- 10) ℃; Relative Humidity < 85% |
| Dimensions | (400 × 350 × 500) mm (L × W × H) |
| Weight | About 40kg |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/42700/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
