Specifications
| Temperature range | -60~150℃ |
| Interior Volume | 225L |
| Inner box size | 50*75*60cm |
| Outer box size | 108*167*110cm |
| Temperature analysis Accuracy | ±0.1℃ |
| Temperature Uniformity | ±1℃ |
| Temperature control Accuracy | ±1℃ |
| Temperature Fluctuation | ±0.5℃ |
| Heating rate | ≈4.0℃/min |
| Internal and external accessories material | The outer box is high-grade cold-rolled sheet paint, and the inner box is stainless steel. |
| Insulation material | High temperature resistant high density formic acid vinegar foam insulation material |
| Chill down the system | Air-cooled/single-stage compressor (-20 ℃), wind and water-cooled/double-stage compressor (-40 ℃~ -70 ℃) |
| Protection device | No fuse switch, compressor overload protection switch, refrigerant high Voltage protection switch, over temperature Humidity protection switch fuse, fault warning system |
| Accessories | Viewing window, 50mm test hole, PL box light, Shelf, wet and dry cloth |
| Controller | Korean "TEMI" or Japanese "OYO" card, choose |
| Compressor | "Taikang" or German Bitzer (optional) |
| Power | 220VAC±10%50/60Hz & 380VAC±10%50/60Hz |
| meet the standard | GB2423.1、GB2423.2、GJB150.3、GJB150.4、IEC、MIL |
| Cooling rate | About 1.0 ℃/min (a drop of 5 to 10 ℃ per minute is a special selection condition) |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
