Specifications
| Capacity | 0~200KG |
| Accuracy grade | Level 0.5 |
| Maximum load | 3KG |
| Effective force range | 0.02/100-100% |
| Test force resolution | Maximum load 250,000 code; inside and outside are not divided into gears, and the whole process resolution remains unchanged |
| Effective test width | 25mm |
| Efficient stretch space | 600mm (without fixture) |
| Test speed | 5~500mm/min |
| Speed Accuracy | +/- 0.5% of the indication |
| Measurement Accuracy | +/- 0.5% of the indication |
| Acquisition sensing method | High-Precision Sensors |
| Control system | Stepper driver + stepper motor |
| Software measurement and Control system | Digital Closed Loop Control system, which can realize the functions of constant stress, constant strain, constant displacement and test |
| Test bench lifting device | Computer digital control/manual jog control |
| Safety protection device for test bench | Software automatic diagnosis, electronic limit |
| re-test | Manual can return to the initial position of the test at the highest speed, and automatic can return automatically after the test is over |
| Overload protection | Maximum load value can be set, automatic protection |
| Fixture configuration | Customized according to user product sample requirements |
| optional | A set of brand Lenovo LCD computers; a printer |
| motor | 400W |
| Host Weight | About 75kg |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/42732/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
