Specifications
| way | Double duct forced convection |
| Temperature range | RT+10~300°C |
| Temperature Resolution | 0.1℃ |
| Temperature Fluctuation | ±1.0℃ |
| Temperature Uniformity | ±2.0% |
| Interior | Mirror stainless steel plate |
| Exterior | Cold rolled steel plate, surface resistance painting |
| Thermal insulation material | aluminum silicate fiber |
| heater | Stainless steel heating tube |
| Rated power | 2.3KW |
| Exhaust port | Inner diameter 28mm * 1, top |
| Temperature Control mode | Digital tube dual row PID |
| Temperature setting | Tap the four-button settings |
| Temperature representation | Type D: Measured temperature display: 4-digit digital upper display; set temperature display: 4-digit digital lower display |
| Timer | 0~9999 minutes (with Timer and waiting function) |
| Run function | Fixed-value operation, regular operation, automatic stop, scheduled start |
| Program Mode | optional |
| Additional features | Deviation correction, menu button lock, power outage compensation, power outage memory |
| Sensors | Pt100 |
| Inner size | 500 * 450 * 550mm (W * D * H) |
| Dimensions | 617 * 639 * 953mm (W * D * H) |
| Packing size | 742 * 718 * 1080mm (W * D * H) |
| Inner Volume | 125L |
| Shelf load bearing | 15kg |
| Shelf Layers | 11th floor |
| Shelf spacing | 40mm |
| Power | (50/60Hz) Rated current AC220V/10.5A |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/43003/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
