Specifications
| Measurement range | 1~ 99999 times (the range can be increased as needed) |
| folding angle | 135°±2° |
| Tension adjustment range | 4.9N~14.7N |
| Folding Head Stitching Specifications | 0.25Mm, 0.50mm, 0.75mm, 1.00mm four optional |
| Fold mouth fillet radius | R0.38mm±0.02mm |
| The tension change caused by the swirl/spin eccentricity of the folding collet is not greater than | 0.343N。 |
| Power | AC220V±10％ 50Hz |
| Operating Environment | Temperature 0~40 ℃, Relative Humidity does not exceed 85% |
| Instrument Gross Weight | ≤ 30kg |
| show | 5 inch touch screen |
Packing list
Complete machine X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/43027/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
