Specifications
| Drawdown blade Accuracy | ±0.003mm |
| Application thickness range | 0~10mm drawdown blade can be lifted and lowered |
| Application rate | 5~ 180mm/s (< 5mm/s can be customized) |
| Coating size | 300*400mm |
| Vacuum Area | 300*400mm |
| Vacuum aperture | F1.2mm |
| Vacuum hole spacing | 20*20mm |
| Drawdown blade | length |
| Coating rod specification | 1 imported wire rod with Accuracy up to 1μm, effective Application width 300mm |
| Host Power | 220V 50HZ |
| Dimensions | 630*410*520mm |
| Weight | Net Weight 65KG |
| Speed control | Infinitely variable speed |
| Bottom plate material | aluminum alloy |
| Heating temperature range | RT+~180°C |
| Temperature Uniformity | ±3℃ |
| Power | 1500W |
| Vacuum pump size | 380*180*280mm |
| Feeding Capacity | Stainless steel syringe (Max: 100ml) |
| Feeding speed | 0.05-20mm/s (barrel piston speed) |
| Wire rod, drawdown blade material | stainless steel |
| Dosing drum Volume | 1L |
| Heating and insulation components | Application Countertop heating, barrel heating, knife head heating |
Packing list
Film Applicator X1, Feeding System x1, External Vacuum Pump X1, Heating Drawdown blade X1, Imported bar X1, Heating drum x1, Product manual X1,
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/43074/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
