Specifications
| Scraper type | double-channel |
| Number of grooves | 2 |
| range | 0~150μm |
| Scale unit | μm |
| scraper material | Carbide steel |
| Scraper size | 155*50*13mm |
| Groove size | 13*120mm |
| Drawdown blade size | 68*40*6.5mm |
| Applicable standards | GB/T 1724-93、GB/T 13217.3-91 |
| Net Weight | 0.9kg |
| Graduation | 10μm |
Packing list
Fineness meter x1, doctor blade x2, Encasement box x1
