Specifications
| Accuracy | ±0.003mm |
| Application thickness range | 0~10Mm drawdown blade can be lifted and lowered |
| Application rate | 5~ 180Mm/s (< 5mm/s can be customized) |
| Application speed | Digital display, different speeds |
| Coating rod specification | Accuracy 0.001mm (Application thickness is determined according to the bar model) |
| Host Power | Voltage 220V 50HZ |
| Dimensions | 1000Mm * 850mm * 1000mm (non-standard customization, subject to actual order) |
| Speed control | Infinitely variable speed |
| Bottom plate material | aluminum alloy |
| Accuracy | 0.001mm |
| Customizable functions | Automatic Inking System |
| Customizable functions | Jet system device, UV solid device |
| Feeding principle | Air source pressure flows out |
| Feeding motion mode | Reciprocating linear motion |
| Feeding traverse speed | 2-150mm/s |
| spit Volume | Adjustable (by adjusting the air pressure and the running speed of the discharge port) |
| Shaft drive mode | Timer belt |
| Feeding system air source | 0.6Mpa, can be connected to the trachea of φ8 (self-matching) |
| Power Voltage of charging system | 220V,50Hz |
| Tank pressure | Maximum withstand 8Mpa |
| Material of feeding barrel | 304 stainless steel with wall thickness of 4mm |
| Feeding barrel configuration | Safety valve, pressure regulating valve, pressure gauge, air discharge valve |
| Optional | Leakage tank, substrate fixing fixture, trimming horizontal height support foot device, Glass plate, Silicone pad and Weight (for applications with uneven substrate thickness of Application), film width control baffle |
| Speed regulation Accuracy | 1mm/s |
| Heating temperature range | RT+~180℃ |
| Temperature Accuracy | Temperature +/- 3 ℃ |
| Dosing drum Volume | 3L |
Packing list
Film Applicator X1, Drawdown blade X1, Import bar X2, Automatic inking system x1, Product manual X1
After-sales instructions
Warranty days: 365 days
This product is a non-standard product, not a product quality problem, and does not support return and exchange services.
