Specifications
| Sample holding force | > 690kPa (adjustable) |
| Test system sealing | 1Min pressure drop < 10% Pmax |
| Resolution | 0.1kPa; |
| Displacement | (0.02~0.3)m3/min |
| rated pressure | ( 0.6~0.7) |
| test unit | Pa、kPa、kgf、LB |
| Weight | Approx. 50kg |
| Clamp ring diameter | Upper ring: Should be 31.50mm; Lower ring: Should be 31.50mm |
| Volume | 44cm×42cm×56cm |
| Power Supply | AC220V±10% , 50Hz 120W |
| Measurement range | 250~~6000KPa |
| Air pressure source | Min. 6kg/cm ² (customer's own) |
| Oil delivery speed | 170±15ml/min |
| Print test value | MIN Minimum, MAX Maximum, Average, Time |
| gas source | Air compressor (customer-provided) |
| Hydraulic oil | Glycerin 85%, distillation water 15% |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/43403/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
