Specifications
| Viscosity range | 0~100mpa·s |
| measurement Accuracy | ±0.5% |
| Temperature Measurement Range | 0-500℃ |
| Temperature Accuracy | 0.2% |
| Sensors Pressure Range | <25Mpa |
| Sensors Temperature Range | <500℃ |
| Signal response time | 2s |
| material | 316 stainless steel (std.) |
| Environment level | IP68 |
| Power Supply | 24V DC |
| output | Viscosity 4~ 20 mADC; Temperature 4~ 20 mADC |
| Optional Miscellaneous Materials | Hastelloy C alloy |
| process | Standard: Highly polished plus Teflon acid and alkali resistant coating |
| protection level | IP67 |
| explosion-proof standard | ExdIIBT6Gb |
| calibration | Standard sample solution |
| Viscosity unit | 9 options |
| connect | Flange DN40, PN4.0, threaded connection M42 * 1.5, quick chuck user optional |
| Flange standard | HG20592 |
| Modbus-RTU protocol | 485 interface |
Packing list
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/43493/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
