Specifications
| main substrate | PET or other non-breakable materials |
| glue | Water-based paints, solar-based paints |
| Spreader moisture | Adjustable (formed) according to the process |
| Coating method | soak |
| Coating size | Max.500mm |
| substrate | Less than 500mm |
| Roll surface width | 500mm |
| mechanical speed | 1.2M/min (0.1~ 1m/min production speed, depending on the process) The speed can be adjusted slowly |
| unwinding diameter | ≤ φ 400mm (paper core 3 ") |
| winding diameter | ≤ 500mm (paper core 3 ") |
| Heating drying method | External infrared heating, centrifugal fan hot air circulation |
| temperature control | 50~150 ℃ +/- 3 ℃ (maximum 160 ℃ in the intermediate temperature zone) |
| Curl the edges neatly | ±3.0mm |
| Total Installed Power | About 40kW (Power required for electric heating is about 35kW) |
| Equipment external Dimensions | (L x W x H) According to process changes and final design drawings |
| Teflon roller | 4 pieces (installed in front of the Spreader head respectively) |
| Power Supply | Three-phase five-wire 380V 50Hz |
| Unwinding Unit - Type | Single station |
| Unwind Unit - Effective Unwind Width | 500mm |
| Unwinding Unit - Effective Unwinding Diameter | ≤Φ400mm |
| Unwinding Unit - Unwinding Scroll | 3 " (φ 76mm) 1 piece of inflatable shaft (suspended structure) |
| Unwinding Unit - Unwinding Tension Control | Tension automatic control, magnetic particle brake, tension Controller |
| Front Traction Unit - Steel Roller | Φ42x500mm |
| Front Traction Unit - Motor | SEND/0.75KW (servo control) |
Packing list
Host x1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
