Specifications
| Spreader Accuracy | ±0.003mm |
| Spreader thickness range | 0~10Mm drawdown blade can be lifted |
| Coating speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Coating size | 300*400mm |
| Spreader speed | Digital display, different speeds |
| Vacuum Area | 300 * 400Mm (can be customized) |
| Vacuum aperture | Φ1.2mm |
| Vacuum hole spacing | 20*20mm |
| Vacuum pump size | 380*180*280mm |
| Coating rod specification | Accuracy 0.001mm (Spreader thickness is determined according to the rod model) |
| Host Power Supply | 220V 50Hz |
| Weight | Net Weight 65KG |
| speed control | Infinitely variable speed |
| Coating table material | aluminum alloy |
| Spreader Accuracy | 0.001mm |
| configuration function | Air knife + air knife bracket |
| Dimensions | 630*410*520mm |
| Heating Temperature range | RT+~180℃ |
| Temperature Uniformity | ±3℃ |
| UV curing | Portable split UV curing lamp |
| UV Power | 3200W |
| UV main peak wave | 365nm |
Packing list
Film Applicator X1, External vacuum pump X1, doctor blade X1, imported wire rod X1, air knife x1, air knife bracket x1, split UV curing lamp x1, product manual X1
