Specifications
| Spreader Accuracy | ±0.003mm |
| Spreader thickness range | 0.01~10mm |
| Coating speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Spreader time | Digital display, different speed, distance Accuracy control, |
| Drawdown blade length | 400MM material/stainless steel |
| Host Power | 220V 50Hz |
| Dimensions | Width 400 * Length 550 * 180mm Height |
| Weight | Net Weight 45KG (non-standard customized products, subject to actual order) |
| Speed control | Infinitely variable speed |
| Bottom plate material | Glass plate |
| Optional | Leakage tank, substrate fixing fixture, trimming horizontal height support foot device, Glass plate, Silicone pad and Weight (for applications with uneven substrate thickness of Spreader), application width control baffle |
| Customizable functions | Jet system device, UV solid inclusion device, automatic inking system |
Packing list
Film Applicator X1, Drawdown blade X1, Film Applicator fixture x1, cost recovery tank x1, external motor box x1, product manual X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/43741/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
