Specifications
| Drop height | 300~1500Mm adjustable |
| Applicable standards | ISO2248、JISZ0202-87、GB/T4857.5-92 |
| Maximum specimen Weight | 0-80Kg |
| Baseplate thickness | 10mm |
| Maximum specimen size | 800*800*1000mm |
| Impact Panel Size | 1700*1200mm |
| Drop height error | ±10mm |
| Test bench Dimensions | About 1700 * 1200 * 2315mm |
| Net Weight | About 300kg |
| Control mode | electric |
| Drop height error | 1% |
| Hit panel parallel error | ≤ 1 degree |
| The angle error between the falling surface of the piece and the horizontal during the falling process | ≤ 1 degree |
| Power | AC380V 50HZ |
| Power | 1.85KWA |
| temperature | 5 ℃~ + 28 ℃ (average temperature within 24 hours ≤ 28 ℃) |
| Relative Humidity | ≤85%RH |
| Power supply conditions | Three-phase four-wire + protective ground wire |
| Voltage range | AC（380±38）V |
| Allowable Frequency Range | （50±0.5）Hz |
| The grounding resistance of the protective ground wire is less than | 4Ω |
Packing list
Complete machine X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/43749/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
