Specifications
| Detection wire rope diameter range | Φ1.5~ 300mm (Sensors of different series specifications need to be configured) |
| Sensors relative speed to wire rope | 0.0~6.0 m/s；建议：0.3~1.5m/s |
| Sensors guide sleeve and wire rope clearance | Recommended 2~ 6mm, allowable clearance: 0~15mm |
| Qualitative detection capability of broken wire defect (LF) | The Accuracy rate of qualitative detection of single centralized broken wire is 99.99% |
| Quantitative detection capability of broken wire defect (LF) | The number of broken wires in a single place allows one or one equivalent root to be misjudged |
| The Accuracy of quantitative detection of more than 100 times without error in the number of broken wires in a single place | Accuracy ≥ 95% |
| Detection sensitivity Repeatability allowable error | ±0.055% |
| Detection Accuracy indication allowable error | ±0.2％ |
| Position (L) detection capability | Detection length indication percentage error: +/- 0.2% |
| Power | Computer battery powered 5V |
| Sensors Weight | Common specification < 10kg |
| Ambient Temperature | -10℃~40℃ |
| Atmospheric pressure | 86~106Kpa |
| Relative Humidity | ≤85% |
| Accessories | Diameter above 58mm is optional for customized Sensors; computer |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
