Specifications
| Probe type | N1 |
| Measurement principle | Eddy Current |
| Measurement range | 0~1250μm |
| Low resolution | 0.1μm |
| An indication of calibrating error | ±（3%H+1） |
| An indication of two-point calibrating error | ±[（1~3%)H+1] |
| Minimum radius of curvature | Convex 1.5mm, Concave 9mm |
| minimum area diameter | Φ7mm |
| Basic critical thickness | 0.5mm |
| temperature | 0~40℃ |
| Humidity | 20%~90% |
| Power Supply | AA type alkaline battery 1.5V two |
| Dimensions | 130 * 70 * 25Mm (host) |
| Weight | 350g |
| Shell material | Metal shell |
| optional | Standard test piece, probe, pc communication |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/43852/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
