Specifications
| Probe type | F1/N1 |
| Measurement principle | Magnetic Induction/eddy Current |
| Measurement range | 0~1500μm |
| Low resolution | Below 100um 0.1um, above 100um 1um |
| An indication of zero calibrated error | ±（3%H+1） |
| An indication of two-point calibrating error | ±[（1~3%)H+1] |
| Minimum radius of curvature | Convex 1.5mm, Concave 3mm |
| minimum area diameter | Φ7mm/Φ5mm |
| Basic critical thickness | 0.5mm/0.3mm |
| temperature | 0~40℃ |
| Humidity | 20%~90% |
| Power Supply | AA type alkaline battery 1.5V two |
| Dimensions | 112 * 70 * 23Mm (host) |
| Weight | Approx. 80g |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/43854/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
