Specifications
| Inner & Outer Chamber Material | Stainless steel #304 |
| Temperature range | -30℃+100℃ |
| Optional inner box action | Installed finished shoes are resistant to bending, outsole is resistant to twisting, and leather is flexible and fixture. |
| Protection device | Thermal protection shutdown, leakage protection shutdown over temperature protection, overload protection and other functions |
| Control Accuracy | ±0.3℃ |
| Temperature Uniformity | ±2℃ |
| Cooling rate | It takes about 45 minutes to reach -30 ℃ at room temperature |
| Refrigerant | R404 Environmental Refrigerant |
| Compressor | Original fully enclosed |
| Compressor start delay | 5min |
| Power consumption | (4-6)KW |
| Thermal Insulation | Hard Foam & Glass Cotton |
| Counter | LCD,0~999,999 |
| window | (210 × 35 × 270) mm, two-grid vacuum layer |
| Window light | P1, 5W |
| Power | AC380V 50Hzor1 AC220V 50HZ |
| motor | Belt-less multi-imported gear reduction motor |
| Inner box size | 600 × 600 × 550mm, mainly based on the actual size (3 stations for ROSS sole fixture + 2 stations for heel-up sole folding resistance) |
| Volume | 1100 × 1050 × 1600mm, mainly based on the actual size |
| Weight | 420kg |
Packing list
machine x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/43856/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
