Specifications
| Thickness Measurement Range | 0~1500μm |
| Measurement error | +/- (3% H + 1) um, H is the actual thickness of the measured object |
| Environmental temperature | 0~40 ℃, F3 high temperature: 0-300 ℃ |
| Power Supply | AA type alkaline battery 1.5V two |
| Dimensions | 150*80*30mm |
| Weight | 300g |
| statistical function | MAX Maximum (MAX), MIN Minimum (MIN), Average (MEA), Number of measurements (No) |
| Data storage | 500 pieces of data |
| Calibrated mode | One point calibrated, two point calibrated, basic calibrated |
| Measurement principle | Eddy Current |
| Thickness probe | N1 |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/43860/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
