Specifications
| Furnace material | High quality aluminum oxide polycrystalline fiber |
| Heating workpiece | High quality resistance wire |
| Temperature measuring element | Thermocouple K |
| Temperature control instrument | Temperature Control system adopts artificial intelligence adjustment technology, with PID adjustment, self-tuning function, 8-30 sections of rising and cooling program. |
| Common temperature | ≤1000℃ |
| maximum temperature | 1200℃ |
| Recommended Heating rate | 10℃~15℃/min |
| Thermostatic Accuracy | ±1℃ |
| Furnace tube material | Quartz tube |
| Heating area | 350mm |
| Thermostatic zone | 150mm |
| flange | The double ring sealing technology is used to effectively improve the atmosphere of the flange. |
| Vacuum system | 2L vacuum pump |
| Sealing system | Silicone O-ring extrusion sealing is used at both ends of the furnace tube |
| Reach vacuum | -0.1mpa |
| Power | AC220V 50/60HZ |
| Furnace size | φ 40 * 900mm (diameter * length) |
| Rated power | 2kw |
