Specifications
| Rated Voltage | AC220V±10% |
| Rated Frequency | 50/60HZ |
| Input Power | 1050 W |
| output power | 600 W |
| Rated torque | 38N*cm |
| Duty Cycle | S1 (continuous) |
| Control mode | Combined control knob |
| Speed range | 2000~15000rpm |
| Speed regulation mode | stepless |
| Timer Range | 1～1000 min |
| Rotation speed display | LED |
| Rotation speed dynamic detection | Yes |
| Rotation speed memory function | Yes |
| Overload protection | Yes. |
| Protection level | IP20 |
| Work head material | Stainless steel 316 |
| Working head diameter | Φ 42 mm |
| rotor diameter | Φ 24 mm |
| stator-rotor clearance | 0.5 mm |
| Maximum circumferential velocity | 18.9 m/s |
| immersion depth | 38～250 mm |
| Stator standard configuration | Square hole/long hole/round hole/large round hole |
| Process type | batch processing |
| Processing Capacity | 100～20000 ml |
| Max. Processing Viscosity | 10000 mPa.s |
| maximum temperature | 180 ℃ |
| PH value | 2～13 |
| Sterilizing method | Chemical wet treatment |
| Suspension particle size | 15～65μm |
| Emulsion particle size | 5～30μm |
| Environmental temperature | Not more than 40 ° C |
| Allowable Relative Humidity | Not more than 80% |
| Dimension | 215×310×720 mm |
| Machine Weight | 9.0 kg |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/43934/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
