Specifications
| Spreader Accuracy | ±0.003mm |
| Spreader thickness range | 0.02-10MM drawdown blade can be lifted and lowered |
| Coating speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Coating size | 400*500mm |
| Spreader speed | Digital display, different speeds |
| Vacuum Area | 400 * 500Mm (can be customized) |
| Vacuum aperture | Φ1.2mm |
| hole spacing | 20*20mm |
| Drawdown blade | length |
| Host Power | 220V 50Hz |
| Weight | Net Weight 65KG |
| Speed control | Infinitely variable speed |
| Bottom plate material | aluminum alloy |
| Vacuum pump size | 380*180*280mm |
| Optional | Leakage tank, substrate fixing fixture, trimming horizontal height support foot device, Glass plate, Silicone pad and Weight (for applications with uneven substrate thickness of Spreader), application width control baffle |
| Customizable functions | Jet system device, UV solid inclusion device, automatic inking system |
Packing list
Film Applicator X1, external vacuum pump X1, doctor blade X1, product manual X1
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/43982/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
