Specifications
| resolution | 0.1 μm (less than 100 μm) or 1 μm (greater than 100 μm) |
| Precision | +/- (1~ 3% n) or +/- 2.5 μm |
| test range | 0~1250μm (Measurement range can be customized) |
| Measurement area | 6mm |
| thinnest substrate | 0.3mm |
| Minimum surface | F-type convex 1.5mm/concave 25mm NF-type convex 3mm/concave 50mm |
| Power Supply | 2X1.5AAA No. 7 battery |
| operating conditions | Temperature -5~ 50 ℃ |
Packing list
Host X1, iron-based X1, aluminum-based X1, calibrated diaphragm X1, measurement Sensors X1, portable case X1, instruction manual X1
After-sales instructions
Warranty days: 1095 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/44180/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
