Specifications
| Weighing readability | 0.001g |
| Maximum weighing value | 120g |
| Water readability | 0.01% |
| Sensors | Imported German HBM |
| Heating source | Halogen lamp (ring 450w) |
| Heating mode | Gentle, standard, fast |
| How to end the measurement | Automatic shutdown, manual shutdown, timed shutdown |
| display parameters | Test temperature, test time, Moisture content, Solid content, Weight after drying, Dynamic Linear dispersion, Moisture regain, Solid content, Weight loss, Dry Weight, Test method, Sample name, MAX Maximum, MIN Minimum, Average |
| Data storage | 100 groups |
| user management | Password protection, multiple users, automatic locking |
| shutdown standard | Freely definable |
| Pan Size | φ 90mm [stainless steel material] |
| Heating Temperature range | RT+40~200℃ |
| Display | 5-Inch touchscreen display |
| Communication interface | Standard RS232 Communication interface, can connect printers, PCs and Miscellaneous peripherals, can be customized USB |
| Dimension | 220×340×210mm |
| Net Weight | 3.8kg |
| Outer box size | 430×290×330mm |
| Gross Weight | 4.8kg |
Packing list
Host x1, stainless steel sample plate x2, tripod bracket x1, heat collecting plate x1, correction weight x1, certificate x1, manual x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/44229/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
