LANDTEK HT6510DO Shore Durometer Plastic Medium to Hard Rubber Material

SE
Hardness value is greater than 90C, less than 20D, Accuracy ≤ +/- 1H, display parameter Hardness value/average value/MAX Maximum, Measurement unit HA/HB/HC/HD/HE/HDO/HO/HOO, Display range 0HA~ 100 HA (HB/HC/HD/HE/HDO/HOO/HMF/HF).
$276.00/set
PromotionLoading...
Coupon
Model：
Certificate
Contact
Details SPEC Con CAT OI
Similar products

LANDTEK HT6510DO Shore Shore DurometerSPEC

LANDTEK HT6510DO Shore Shore DurometerDetails

LANDTEK HT6510DO Shore Shore DurometerPacking list

SKU
NB044279
Crimping head size
R1.2 hemisphere
Application
Moderate hard rubber, thermal plasticity plastics, thermal plasticity resilience, high density Spinning & weaving ingots
Hardness value
Greater than 90C, less than 20D
Accuracy
≤±1H
Display parameters
Hardness/Average/MAX Maximum
Measurement unit
HA/HB/HC/HD/HE/HDO/HO/HOO
Display range
0HA~100 HA（HB/HC/HD/HE/HDO/HOO/HMF/HF）
Measurement range
10HA~90 HA（HB/HC/HD/HE/HDO/HOO/HMF/HF）
Resolution
0.1H
Low Voltage prompt
√
Automatic shutdown function
√
Operating Environment
Temperature: 0~50 ℃; Humidity:~ 80% RH
Power
4 AA batteries
Dimensions
162mm*65mm*28mm
Weight
170G (without battery)
HT6510DO
Shore Shore Durometer
Hardness value is greater than 90C, less than 20D, Accuracy ≤ +/- 1H, display parameter Hardness value/average value/MAX Maximum, Measurement unit HA/HB/HC/HD/HE/HDO/HO/HOO, Display range 0HA~ 100 HA (HB/HC/HD/HE/HDO/HOO/HMF/HF).
LANDTEK HT6510DO Shore Durometer Plastic Medium to Hard Rubber Material Picture

Features

  • Comply with the following standards: "Rubber Pocket Hardness Tester Indentation Hardness Test Method" GB/T 531-1999; "Plastic Shore Hardness Test Method" GB/T 2411-80; DIN 53505; ISO 868; ISO 7619; ASTMD 2240; JISK7215 .

  • Average calculation function.

  • Maximum value latch function.

  • Under Voltage alarm indication function.

  • Use "USB data cable output" to communicate with PC.

  • Provides Bluetooth data output selection.


FAQ
QOur laboratory needs to test the Insertion Hardness of Rubber and Plastic to meet national standards. Is there any recommendation?
A HT6510DO conforms to national standards such as GB/T 531-1999 and GB/T 2411-80, and also supports multiple standards such as ISO and ASTM. It has its own data output function and can be connected to a computer through USB or Bluetooth to facilitate laboratory data recording and export.
QI want to test some hard rubber and plastic parts, which Shore Shore Durometer is suitable?
A HT6510DO is suitable for hard rubber and thermal plasticity plastics. Measurement range covers Shore Type A to Type D. It is especially suitable for materials with Hardness value greater than 90C or less than 20D. The accuracy reaches +/- 1H. It also has the function of average value and MAX Maximum locking. The measurement results are very reliable.
