CHINA QXD-25 double-channel Fineness Meter, stainless steel material 0~25μm
Double-channel, stainless steel, range 0-25μm, Graduation 0.7μm, there are three units of μm, Hegman, mils, groove size 140 × 12.5mm.
Model：
QXD-25
Factory
Similar products
-
CHINA QXD-25 zirconia ceramic fineness gauge double-channel Fineness gauge 0~25μm$ 459.00SE -
JINGKELIAN QXP 0-25S ISO Fineness of Ground Gauge Fineness gauge 0~25μm/2.5μm$ 192.00SE -
TRUIT TR 1202/025 double-channel pigment Fineness gauge 0~25μm$ 187.00SE -
JINGKELIAN QXP 0-25S ISO Fineness of Ground Gauge with Third Party Measurement Certificate$ 254.00SE -
TQC VF2111 double-channel Grindometer 0-25 µm with calibrated certificate$ 980.00SE
Factory QXD-25 Double-channel Fineness gaugeSPEC
Factory QXD-25 Double-channel Fineness gaugeDetails
Factory QXD-25 Double-channel Fineness gaugePacking list
- SKU
- NB044281
- scraper material
- stainless steel
- range
- 0~25μm
- Graduation
- 0.7μm
- Number of grooves
- Article 2
- Groove size
- 140*12.5mm
- Scraper type
- double-channel
- Dimensions
- 175 x65 x 13mm
QXD-25
Double-channel Fineness gauge
Double-channel, stainless steel, range 0-25μm, Graduation 0.7μm, there are three units of μm, Hegman, mils, groove size 140 × 12.5mm.
Introduction
The scraper Fineness Meter is an instrument used to measure the particle size distribution or particle size of coatings, inks, pigments, cosmetics and other substances. It is done by coating the sample on a flat substrate and then using a scraper to scrape the material flat. The particle size and dispersion of the sample are evaluated based on the thickness of the material remaining on the scraper or the distribution of the particles.
The QXD-25 double groove Fineness Meter is a standard scraper Fineness Meter with a measuring range of 0~25μm, a groove size of 140Ã12.5mm, and is made of wear-resistant stainless steel.
Applications
It is used to test highly corrosive materials in coatings, paint pastes, plastics, inks, papers and other fields.
