LANDTEK FM-204G Feed grain Hardness Gauge

SE
Test range 0Kgf-20Kgf, 0N-196N, 0F-4426F, resolution 0.01Kgf, 0.1N, 0.0126F, diameter test range 15mm, accuracy +/- 0.5% FS (range) +/- 1 digital peak, unit kgf, gf, N, Lbf, Measured value peak, instantaneous value.
$350.00/set
PromotionLoading...
Coupon
Model：
Certificate
Contact
Details SPEC Con CAT OI

LANDTEK FM-204G Feed grain Hardness GaugeSPEC

LANDTEK FM-204G Feed grain Hardness GaugeDetails

LANDTEK FM-204G Feed grain Hardness GaugePacking list

SKU
NB044353
test range
0Kgf-20Kgf,0N-196N,0F-4426F
Resolution
0.01Kgf,0.1N,0.0126F
Diameter test range
15mm
Accuracy
+/- 0.5% FS (range) +/- 1 digital peak
unit
kgf, gf, N, Lbf
Measured value
Peak, instantaneous value
show
Four-digit large LCD, forward and reverse dual display
Backlight
Backlight
allowable load
150% F.s (if it exceeds 110% F.s, there will be a beep alarm)
Power
2 AA batteries, or 5V DC Power
Operating temperature
0°C~40°C
Operating humidity
<80%
Operating Environment
No source and corrosive medium around
Net Weight
390g
size
211mmx80mmx36mm
FM-204G
Feed grain Hardness Gauge
Test range 0Kgf-20Kgf, 0N-196N, 0F-4426F, resolution 0.01Kgf, 0.1N, 0.0126F, diameter test range 15mm, accuracy +/- 0.5% FS (range) +/- 1 digital peak, unit kgf, gf, N, Lbf, Measured value peak, instantaneous value.
LANDTEK FM-204G Feed grain Hardness Gauge Picture

Features

  • High precision and high resolution.

  • Digital display, no parallax.

  • Four measurement units of N (Newton), kg (kilogram), lb (pound), and g (gram) are available for selection and mutual conversion.

  • Peak hold function. Maintain peak value display until manually cleared to zero.

  • It can be powered by alkaline batteries; it can also be powered by a 5V DC power supply.

Product Description

FM-204G series grain feed pellet Hardness Tester is a newly designed and developed digital display grain feed pellet Hardness Tester. It has the advantages of high precision, easy operation, and portability.

The scientific usage test range is 10%~100% of the full scale. The measurement department recommends not to use less than 1% of the full scale. At the same time, after the instrument and the object under test are in place and before starting the test, press the ZERO key to clear to eliminate the weight of the fixture.


FAQ
QI want to measure the Hardness of feed pellets, is there any suitable instrument recommended?
A FM-204G feed grain hardness gauge designed for feed pellets, test range 0-20kgf, accuracy +/- 0.5%, can directly display Hardness peak, simple operation with backlight display, suitable for quality control in feed mills.
QWhat size particles can this hardness gauge measure? Can the unit be switched?
A The test diameter range of FM-204G is 15mm, which is suitable for common feed particle sizes. Support one-click switching of four units: kg, N, lb, and g. For example, to measure the Newton value required by international customers, you can directly press the unit button to convert it, which is very convenient.
QIt needs to record peak data for a long time. Does this instrument have relevant functions?
A Yes, its peak hold function can lock the test MAX Maximum until it is manually cleared, so that you will not miss data when doing batch inspection. With the front and back dual displays, you can see the value clearly from different angles, improving the detection efficiency.
