Specifications
| UV lamp group | 3.2KW*1PCS |
| UV main peak | 365nm |
| UV lamp quality assurance | More than 1000 hours |
| Power | Adopt corresponding matching copper wire transformer |
| Light box adjustment | External handwheel scale adjustment |
| Light box height | The height can be adjusted by external handwheel 80mm-180mm, and the lift can be adjusted. |
| Conveying speed | 0.5-20 m/min |
| Conveying width | 400mm |
| Inlet height | 10-100Mm (adjustable) |
| Control mode | push-button interface control |
| Total Power | About 3.2KW |
| Power | AC220V50Hz |
| Machine Dimensions | About 1500mm * 700mm * 1750mm (length * width * height) |
| Feed section length | 300Mm, discharge section length 300mm |
| Conveying surface height from ground | 750mm±25mm |
Packing list
machine x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/44365/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
