Specifications
| Measurement structure | D/8，SCI |
| Measurement Repeatability | ΔE*ab≤ 0.03 |
| Display Accuracy | 0.01 |
| Measurement caliber | There are 2 stable types and smart types in total: φ 6mm, ▽ 6mm |
| Measurement index | CIE-Lab, color difference Delta E * ab |
| Light source conditions | D65 |
| Lighting source | Full Band Balanced LED Light source |
| Measurement Observation method | visual |
| Calibrate | Manual calibration |
| Software support | Andriod, iOS, Windows, WeChat Mini Program |
| Accuracy guarantee | Guaranteed Measurement Qualification |
| Field of view | 10° |
| integrating sphere diameter | 40mm |
| meet the standard | CIE ****5,GB/T 3978,GB 2893,GB/T 18833,ISO7724-1,ASTM E1164,DIN5033 Teil7 |
| spectroscopic mode | Nano Integrated Light spectrum device |
| Sensor | Silicon photodiode array, double 16 groups |
| wavelength interval | 10nm |
| Wavelength range | 400-700nm |
| Reflectance Measurement Range | 0-200% |
| Reflectance resolution | 0.01% |
| Measurement mode | Single measurement, average measurement (2~ 99 times) |
| Measurement time | About 1 second |
| interface | USB, Bluetooth |
| screen | IPS full-color screen, 2.4 inches |
| Battery Capacity | Single charge can be continuously measured 8000 times, 3.7V/3000mAh |
| Light source lifetime | 10 years 1 million times |
| language | Simplified Chinese, English |
| Storage | Instrument: 100 master standards, 10,000 samples; APP Mass storage |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/44516/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
