Specifications
| Measurement range | 15~10000mN.m |
| Accuracy | Below 50mN +/- 0.6mN, remaining +/- 1% |
| Resolution | 0.1mN |
| Indication variability | ≤1% |
| bending length | 50mm、25mm、20mm、15mm、10mm、5mm(±0.1mm) |
| bending angle | 7.5°±0.3、15°±0.3 |
| Test speed | 200°±20°/min |
| printout | modular integrated thermal printer |
| Display | 5.7In LCD display with Linear dispersion diagram |
| printout | modular integrated thermal printer |
| Operating Environment | Temperature (20 +/- 10) ℃, Humidity < 85% |
| Dimensions | 340*330*340mm |
| Weight | About 28kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/44572/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
