Specifications
| Capacity selection | 1T (Miscellaneous force value optional) |
| Force measurement Accuracy | ±0.5 % |
| Force resolution | 1/300000 |
| Effective force range | 1~100%FS |
| Deformation indication Accuracy | ±0.5% |
| Test speed range | 1~ 500mm/min (can be set arbitrarily) |
| test maximum stroke | Effective 500mm |
| Test space | Left and right 380mm, front and rear < unk > |
| Force unit | g、kg、N、LB、KN |
| shutdown mode | Upper and lower limit safety settings, emergency stop button, program power and elongation settings |
| Pick up method | During the test, manual point taking and preset point taking (20 points) can be used for tensile and pressure holding tests |
| Machine size | 850×510×1400mm(W×D×H) |
| Machine Weight | About 120kg |
Packing list
Tension machine X1, operation software X1, computer X1, strong pliers stretching fixture X1, manual X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/44631/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
