Specifications
| Capacity | 500 kg |
| Paper tube outer diameter | Within 400 mm |
| Plate size | 400*400mm |
| Working Travel | 600mm |
| Pressurization speed | 10~80mm/min |
| Analysis | 1/5000N |
| Force resolution | 0.1N |
| Accuracy grade | Level 1 |
| displacement unit | mm、cm、in |
| Unit switch | kgf、gf、N、kN、Lbf |
| stress unit | MPa、kPa、kgf/cm2、lbf/in2 |
| Control mode | Microcomputer Control (Optional Computer Operating system) |
| monitor | Electronic LCD display (optional computer display) |
| software function | Chinese and English language swap |
| shutdown mode | Overload shutdown, automatic shutdown for test piece damage, automatic shutdown for Upper/Lower limit setting |
| Safety Devices | Overload protection, limit element protection device |
| Machine power | AC variable frequency motor drive Controller |
| Mechanical system | High-precision screw |
| Power | AC220V/50HZ~60HZ 4A |
| Weight | Approx. 130 kg |
Packing list
host X1, manual X1, warranty card X1, certificate X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/44672/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
