Specifications
| Drive mode | Hydraulic cylinder drive (extrusion); hydraulic cylinder control (acupuncture) |
| Force range | 1~ 20kN (extrusion); |
| Force measurement Accuracy | 0.1N (extrusion ）； +/- 1% (acupuncture) |
| unit conversion | kg, N, lb |
| Force display | PLC touch screen display |
| Box material | Inner box stainless steel, outer box Cold rolled steel plate Spray treatment |
| feature | The rear side of the box is designed with a discharge trend and a pressure relief device, and the box is equipped with a lighting lamp |
| Extrusion stroke (extrusion) | 200Mm or 300mm; |
| Battery extrusion head (extrusion) | Standard extrusion head, area ≥ 20cm ²; |
| Extrusion degree (extrusion) | The extrusion pressure reaches 13 +/- 0.2kN for 1 min |
| Test space (extrusion) | 300x300x300mm； |
| Dimensions (extrusion) | Approx. 700x800x1830mm; |
| Weight (extrusion) | About 220kg |
| Power supply (extrusion) | AC380V， 50HZ |
| Steel needle (acupuncture) | φ 5mm~ φ 8mm high temperature resistant tungsten needle, length is 100mm (can be specified) |
| Acupuncture stroke (acupuncture) | 200Mm or 300mm |
| Clippable battery distance (acupuncture) | 200mm |
| Acupuncture speed (acupuncture) | 10~80Mm/s (can be specified) |
| Acupuncture force value (acupuncture) | 1~ 200Kg (optional) |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
