Specifications
| I/O Subsystem | 7 inch touch screen |
| Angle measurement | Image method, automatic measurement |
| vibration amplitude | 3Mm, 14mm (optional) |
| Tap Frequency | 0~300 rpm, adjustable |
| Repeatability Error | ≤3% |
| size | 680mm*380mm*750mm |
| Power | AC220V±10V 50Hz |
| Electronic Reporting Software PCTSee Support Platform | Windows 10; Android |
| Maximum print format | A4 |
| Network connection | Wireless |
| 3C certification number | 2020010904358225 |
| Printer Weight | About 1.8KG (bare metal) |
| Printer size | 275x110x60mm |
| Print speed | 50mm/s |
| Balanced connection interface | RS232 |
| Balance size | 213mm*195mm*75mm |
| Balance resolution | 0.01g |
| Balanced Power | AC 220±10%，50Hz±1Hz |
| Balanced operating temperature | 0~40° |
| Balanced Humidity | ≤80%RH |
| Vibration sieve specification (aperture) | 45μm，75μm，150μm，250μm，355μm，425μm，1000μm，1400μm，2000μm |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/44845/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
