Specifications
| Measurement stroke | X sentire:500mm;Y sentire:400mm;Z sentire:200mm |
| X/Y axis Accuracy | (3+L/200)μm |
| X/Y Optical inspection scale resolution | 1μm |
| Measurement mode | fully automatic |
| function | Point, line, circle, distance between two points, angle measurement and other basic functions |
| file export | Measurement data can be imported into Excel/Word or CAD format documents |
| Machine load-bearing | 30kg |
| Power requirements | 220V±10% 50/60Hz |
| Suitable for the environment | Temperature: 20-250C Humidity: 50% -60% |
Packing list
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/44868/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
