Specifications
| Spreader Accuracy | ±0.003mm |
| Spreader Film thickness range | 0~10Mm drawdown blade can be lifted |
| Coating speed | 0.1-40mm/s |
| Coating size | 350*600mm |
| Rod Film thickness range | 1~ 571.5 μm (Spreader Film thickness according to bar type) |
| vacuum aperture | Φ1.2mm |
| Vacuum hole spacing | 20*20mm |
| Vacuumpump size | 380*180*280mm |
| Mayer Rod Accuracy | ±0.001mm |
| Host Power Supply | 220V 50Hz |
| net Weight | 65KG |
| speed control | Infinitely variable speed |
| Coating table material | aluminum alloy |
| Spreader Accuracy | 0.001mm |
| configuration function | Air knife + air knife bracket |
| Dimensions | 630*410*520mm |
| Heating temperature range | RT+~180℃ |
| Temperature Uniformity | ±3℃ |
| Air knife gap | 0.05mm |
| Air knife Accuracy | ±0.002mm |
| Coating method | Bar + drawdown blade + air knife |
Packing list
Film Applicator X1, External Vacuum Pump X1, Drawdown blade X1, Imported bar X1, Air knife x1, Air knife bracket x1, Product manual X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/44876/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
