Specifications
| Mechanical barrel length | Infinity system (∞) |
| magnification | 40X-1600X |
| Stage size | Double-decked mobile platform 155 × 145mm |
| Movement range | 80×50mm |
| pupil distance | 55-75mm |
| Focusing device | 30 mm coarse fretting coaxial focusing mechanism with limit, coarse focusing tension adjustment device, fine-tuning grid value: 0.002mm |
| Brightfield condenser | N.A.1.25 Adjustable medium Abemin field condenser with variable light bar |
| darkfield condenser | N.A.0.90 Adjustable Medium Infinity Abbe Dark Field Condenser |
| Color filter | Blue, yellow, green |
| Light source | 6V/20W halogen lamp, Kohler lighting, adjustable luminance |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/44893/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
