Specifications
| Mechanical barrel length | 160mm |
| magnification | 40X-640X |
| Stage size | Cube stage, size: 190mm × 170mm; Glass plate: φ 110mm; Movement range: 120mm × 80mm |
| pupil distance | 50-75mm |
| Focusing device | Coarse and fretting coaxial focusing, using rack and pinion transmission mechanism, fretting grid value: 0.002mm |
| condenser | Long working distance condenser with variable light bar, working distance: 55mm |
| lighting system | 12V 20W halogen lamp, adjustable luminance |
| Power | AC 85V-230V(50/60HZ) |
| Computer imagery system: | (1) Digital CMOS camera, 5 million pixels, with geometric measurement analysis software, the software for point, line, circle and arc, straightness, roundness, area and other measurements; (2) MCL-Z adapter mirror; (3) computer self-purchased |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/44898/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
