Specifications
| Mechanical barrel length | Infinity system (∞) |
| magnification | 100X-400X |
| Stage size | Size: 227mm × 208mm; Glass sheet: φ 118mm; Movement range: 114mm × 77mm |
| pupil distance | 50-75Mm, 45 ° tilted eyepiece barrel |
| Focusing device | Coarse and fretting coaxial focusing, using rack and pinion transmission mechanism, fretting grid value: 0.002mm |
| condenser | Extra long working distance condenser, working distance 55mm, with phase contrast device |
| Color filter | Frosted Glass, Blue and Green Color Filters |
| lighting system | 6V30W halogen lamp, adjustable luminance and spatial position |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/44902/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
