Specifications
| Mechanical barrel length | Infinity system (∞) |
| magnification | 100X-400X |
| Stage size | Size: 227mm × 208mm; Glass round platform size: φ 118mm; Movement range: 114mm × 77mm |
| Culture dish pallet one | 86Mm (Width) X129.5mm (Length), suitable for circular culture dishes φ 90mm |
| Culture dish pallet two | 34Mm (width) X77.5mm (length), can be adapted to round culture dishes φ 68.5mm |
| Culture dish pallet three | 57Mm (Width) X82mm (Length), suitable for circular culture dishes φ 60mm |
| Culture dish pallet four | 29Mm (Width) X77.5mm (Length), suitable for circular culture dishes φ 35mm |
| pupil distance | 53-75Mm, 45 ° tilted eyepiece barrel |
| condenser | Extra long working distance condenser, working distance 55mm, with phase contrast device |
| Color filter | Frosted Glass, Blue and Green Color Filters |
| lighting system | 6V30W halogen lamp, adjustable luminance and spatial position |
| Computer imagery system: | Digital CMOS camera 5 million pixels (with geometric measurement analysis software), MCL-Z adapter mirror. (Computer purchase) |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/44903/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
