Specifications
| magnification | 40X-1600X |
| Mechanical barrel length | Infinity system (∞) |
| converter | Five hole converter |
| platform | Double-decked Mobile Platform; Platform size: 189mmx160mm; Movement range: 80mmx50mm |
| Color filter | Plug-in color filters (green, blue, neutral) |
| condenser | N.A.1.25 Abbe condenser with variable diaphragm and color filter |
| Focus | Coarse and fretting coaxial focusing, using rack and pinion transmission mechanism, fretting grid value 0.002mm |
| Polarizing device | The polarizer can rotate 360 degrees, and the polarizer and the polarizer can move the light path |
| Light source | (1) Transmission lighting: halogen lamp 12V/50W, AC85V-230V, luminance adjustable; (2) drop illumination: halogen lamp with aperture light bar and field of view light bar 12V/50W, AC85V-230V luminance adjustable |
| buy | Drop illumination: halogen lamp 12V100W, AC85V-230V, adjustable luminance |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/44922/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
