Brand：SHSGBM
Model：BM-SG12BD
Name：Research Biological Microscope (Light and Dark Field)
Specifications
| Observatory tube | 30 ° hinged triocular barrel (can be connected to a camera digital device) |
| Mechanical barrel length | Infinity system ∞ |
| tube lens | f=200mm |
| Objective lens converter | Large four-hole converter with DIC jack |
| pupil distance | 50mm-75mm |
| stage | Double-decked mobile platform; Platform size: 189mmX160mm; Movement range: 80mmX50mm |
| Color filter | Color filters (green, blue, neutral) |
| condenser | N.A = 1.25 Abbe condenser with variable aperture diaphragm and color filter |
| Focusing device | Coarse fretting coaxial focusing, fretting grid value 0.002mm |
| Polarizing device | The polarizer can be swirled/spun 360 degrees; the polarizer and the polarizer can be moved out of the light path |
| detection tool | Standard ruler: 0.01mm micrometer |
| Light source | (1) Transmission lighting: Kohler lighting halogen lamp 12V50W, wide Voltage AC85V - 260V, luminance continuously adjustable; (2) reflection lighting: halogen lamp 12V50W, wide Voltage AC85V - 260V, luminance continuously adjustable, with aperture diaphragm and field of view bar |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/44923/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
